Product Description
LED CANOPY & SOFFIT
C Series
BENEFITS:
·New patent design
·Easy to install
·High light efficiency
·Modular,low-profile desigh
·DLC Premium Listed
FEATURES:
·Power efficiency more than 90%
·Efficacy(lm/w):up to 115
·Color Rendering Index(CRI):>70
·Color Temperature(CCT):4000K,5000K,5700K
·Certification:UL/cUL and DLC Premium Listed
·Working temperature(°F):-30°F to 130°F
·Warranty 5 years,L70 Life 70,000 hours
APPLICATIONS:
·Airport,auto dealership,corporate & office,
education,government,heathcare,industrial &
warehouse,municipal,parking,petroleum &
convenience stores,recreation & public venues,
restaurants & hospitality,retail & grocery
Products Code
Watts
Lumen Output
Efficacy(lm/w)
Equivalent
Color Temperature
CRI
Voltage
FLD-CNL-C-30W
30W
3450LM
115.0LM/W
100-175W
4000K/5000K/5700K
>70
100-277/347-480V
FLD-CNL-C-45W
45W
5175LM
115.0LM/W
200W
4000K/5000K/5700K
>70
100-277/347-480V
FLD-CNL-C-60W
60W
6900LM
115.0LM/W
250W
4000K/5000K/5700K
>70
100-277/347-480V
FLD-CNL-C-75w
75W
8625LM
115.0LM/W
300W
4000K/5000K/5700K
>70
100-277/347-480V
FLD-CNL-C-100w
100W
11500LM
115.0LM/W
400W
4000K/5000K/5700K
>70
100-277/347-480V
